TX Valve TUA R404A Internal Equal -40/+10C 3/8"ODF x 1/2"ODF - 68U2285

TX Valve TUA R404A Internal Equal -40/+10C 3/8"ODF x 1/2"ODF

Part Number: 68U2285

TX Valve TUA R404A Internal Equal -40/+10C 3/8"ODF x 1/2"ODF

Part Number: 68U2285
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • TUA / TUAE, Thermostatic expansion valves

    TUA / TUAE stainless steel thermostatic expansion valves are used for liquid injection into evaporators on both refrigeration and air conditioning systems using flourinated refrigerants e.g. R134a, R404A, R407C, R22, R507 and R410A.

    TUA / TUAE valves are compact in design, light weight and have steel / copper bi-metal connections for fast soldering. They are supplied as parts programme, with separate thermostatic element / valve body, and orifice assembly.

    TUA has internal equalization, TUAE external equalization. TUA / TUAE are straightway valves, and have adjustable superheat setting.

    Applications:
    • Traditional refrigeration
    • Heat pump systems
    • Air conditioning units
    • Liquid coolers
    • Ice cube machines
    • Transport refrigeration

    Capacity range:
    • 0.11 – 6.56 TR / 0.42 – 23.1 kW

    Benefits:
    • The use of stainless steel makes the valves light and strong
    • Bi-metal connections for safe, fast and convenient soldering
    • Bi-flow function (TUAE: only orifice 1 – 8 )



  • Balanced PortNo
    Bi-flowNo
    BrandDanfoss
    Capillary Tube Length1.5M
    Danfoss Code Number068U2285
    External Equalised (Yes / No)No
    External Equaliser Connectionn/a
    Inlet Connection3/8" ODF Solder
    Interchangeable OrificePurchase Separately
    Maximum Working Pressure34 bar (500 psig)
    Operating Temperature Range-40°C to +10°C
    Outlet Connection1/2" ODF Solder
    Pressure EqualisationInternal
    RefrigerantR404A / R507
    Supplied with MOPn/a
    TX Valve with Interchangeable Orifice - TypeTUA
    Valve BodyStraightway
  • TX Valve TUA R404A Internal Equal -40/+10C 3/8"ODF x 1/2"ODF
  • Danfoss Orifice Selection Chart



    See the TUA - TUAE orifice range here.
