TX Valve TUBE No8 R134a Ext Equal 8.2kW Bi-Flow 3/8"x1/2"ODF - 68U2025

TX Valve TUBE No8 R134a Ext Equal 8.2kW Bi-Flow 3/8"x1/2"ODF

Part Number: 68U2025

TX Valve TUBE No8 R134a Ext Equal 8.2kW Bi-Flow 3/8"x1/2"ODF

Part Number: 68U2025
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • TUB/TUBE Thermostatic Expansion Valves

    The thermostatic expansion valves TUB/TUBE with fixed orifice are made of stainless steel and therefore especially well suited to refrigeration systems in the food industry and where aggressive environments exist.
    These thermostatic expansion valves have been developed and designed especially for easy and quick soldering into hermetic refrigeration systems.

  • Balanced PortNo
    Bi-flowYes
    BrandDanfoss
    Capillary Tube Length800mm
    Danfoss Code Number068U2025
    External Equalised (Yes / No)Yes
    External Equaliser Connection1/4" ODF
    Inlet Connection3/8" ODF
    Maximum Working Pressure34 bar (500 psig)
    Nominal Capacity (kW)8.2
    Operating Temperature Range-40°C to +10°C
    Orifice Number (Fixed)8
    Outlet Connection1/2" ODF
    RefrigerantR134a / R513A
    Supplied with MOPn/a
    TX Valve with Fixed Orifice - TypeTUBE
    Valve BodyAngleway
  • TX Valve TUBE No8 R134a Ext Equal 8.2kW Bi-Flow 3/8"x1/2"ODF
