Solenoid Coil 13W/380V/50Hz 14W/440V/60Hz AC IP67 - EVR2-40 - 18F6703

Solenoid Coil 13W/380V/50Hz 14W/440V/60Hz AC IP67 - EVR2-40

Part Number: 18F6703

Solenoid Coil 13W/380V/50Hz 14W/440V/60Hz AC IP67 - EVR2-40

Part Number: 18F6703
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • Danfoss solenoid coils are usually ordered separately from valves to allow maximum flexibility, enabling you to select a valve and coil combination to best suit your needs.

    The Danfoss coil program consists of both the easy-to-handle Clip-On system an traditional coils with threaded fastener.

  • Actuator size13.5 mm
    Ambient Temp Range-40°C to +80°C
    BrandDanfoss
    Coil fasteningClip-on
    Danfoss Code Number018F6703
    Duty RatingContinuous
    Electrical connectionTerminal box
    Enclosure rating IPIP67
    Frequency (Hz)50Hz / 60Hz
    Power consumption (VA)23VA/380V/50Hz & 24VA/440V/60Hz
    Power consumption (W)13W/380V/50Hz & 14W/440V/60Hz
    Solenoid Coil TypeBE440CS
    Supply Voltage (V)380V AC 50Hz & 440V AC 60Hz
    Voltage Variation-15% , +10%
