Cubigel Compressor R404A HMBP 1 HP 20.72cc Fan Cooling - MX21TBA

Cubigel Compressor R404A HMBP 1 HP 20.72cc Fan Cooling

Part Number: MX21TBA

Cubigel Compressor R404A HMBP 1 HP 20.72cc Fan Cooling

Part Number: MX21TBA
Cubigel

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • Cubigel have produced more than 100 million compressors and have over 50 years of experience developing compressors for the commercial refrigeration market. Cubigel are focused on the development of quality compressors and condensing units which are supported by European manufacturing in Barcelona, Spain.

    With innovative research and development, Cubigel compressors are designed to optimize energy consumption in response to the issue of global warming. The high efficiency models reduce energy consumption of commercial refrigeration appliances by between 10% and 30%, with respect to standard ranges.

    Cubigel compressors range from 2.2cc up to 34cc and are available in a comprehensive range of refrigerants for today’s market. Due to this large range and a universal drop-in design, Cubigel compressors can be used as a replacement for most common compressors.

    Contact your local Airefrig Australia branch and a sales engineer will assist you with selecting a Cubigel compressor that is appropriate for your application.

  • General Specifications
    Nominal HP1 hp
    Displacement20.7 cm³
    FanFan Cooled
    Suction Line Connection9.7 mm
    Charge Line Connection9.7 mm
    Discharge Line Connection6.5 mm
    Connection Typestub tube
    Weight16.5 kg
    Oil Charge500 ml
    Oil TypeISO VG 32 Ester
    Electrical Specifications
    Voltage220-240 / 1 / 50 Hz
    Motor TypeCSR
    Max Continuous Current9.6 amps
    Locked Rotor Amps37 amps
    Rated Load Amps7.1 amps
    Main Winding Resistance2.14 Ω @ 25 ºC
    Start Winding Resistance6.24 Ω @ 25 ºC
  • Start Capacitor103300
    Run Capacitor102260
    Relay406725
    Overload102198
  • cubigel_d12
  • R404A
    Cond Temp (°C)Evaporating Temperature (°C)
    -15-10-50510
    45Capacity (w)151418982332281733533940
    Input (w)92310081092117412551334
    Current (Amps)4.625.035.435.846.266.67
    50Capacity (w)136517192125258130873645
    Input (w)95510471137122713141401
    Current (Amps)4.775.215.666.116.567.02
    55Capacity (w)121615411917234328213349
    Input (w)98610851183127913741467
    Current (Amps)4.925.45.896.386.887.38

    Note:

    Operating Conditions ASHRAE
    Based on +46 ºC Liquid temp & +35 ºC Suction gas
    R507
    Cond Temp (°C)Evaporating Temperature (°C)
    -15-10-50510
    45Capacity (w)151418982332281733533940
    Input (w)92310081092117412551334
    Current (Amps)4.625.035.435.846.266.67
    50Capacity (w)136517192125258130873645
    Input (w)95510471137122713141401
    Current (Amps)4.775.215.666.116.567.02
    55Capacity (w)121615411917234328213349
    Input (w)98610851183127913741467
    Current (Amps)4.925.45.896.386.887.38

    Note:

    Operating Conditions ASHRAE
    Based on +46 ºC Liquid temp & +35 ºC Suction gas
