Copeland Scroll Compressor 3PH POE Rotalocks Not Included - ZR19M3ETWD961

Copeland Scroll Compressor 3PH POE Rotalocks Not Included

Part Number: ZR19M3ETWD961

Copeland Scroll Compressor 3PH POE Rotalocks Not Included

Part Number: ZR19M3ETWD961
Copeland

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • ZR19M3E-TWD-961 COPELAND ZR SCROLL COMPRESSORS

    ZR Copeland Scroll compressors for comfort and process/precision cooling applications. Applied in the air conditioning and comfort industry for water chillers, rooftops and close control unit applications, scroll compressors are now the most used compression technology replacing reciprocating and screw compressors due to its undeniable superiority.

    Features and Benefits:

    • Copeland Scroll axial and radial compliance for superior reliability and efficiency

    • Wide scroll line-up for R407C and R134a

    • Low TEWI (Total Equivalent Warming Impact)

    • Low sound and vibration level

    • Low oil circulation rate

    • Copeland qualified tandem and trio configurations for superior seasonal efficiency

  • General Specifications
    Nominal HP15 HP
    Displacement250.6 m³/Hr
    Suction Line Connection1-5/8"
    Discharge Line Connection1-1/8"
    Connection Typerotalock
    Weight119 kg
    Oil Charge4.05 L
    Oil TypePOE
    Oil Sight GlassYes
    Electrical Specifications
    Motor Type3PH
    Max Continuous Current37 amps
    Locked Rotor Amps189 amps
    Rated Load Amps26.4 amps
    Crankcase Heater240V 70W (CH-202)
    Line to Line Resistance0.72 OHMS (+/- 7%)
  • Model NumberZR19M3ETWD961
    Suction Service Valve8511928
    Suction Service Gasket020094100PK
    Discharge Service Valve8511928
    Discharge Service Gasket020002803PK
    ContactorMC40A240A
    Thermal OverloadMT323K32
    Crankcase Heater018009118
  • copeland_ZR_04

    Units Dimensions (mm)
    B324
    C357
    D283
    E324
    F552
    G598
  • R22
    Cond Temp (°C)Evaporating Temperature (°C)
    -10-507.21012.8
    45Capacity (w)265003134038640491405393059070
    Input (w)110841112311133111511117211203
    Current (Amps)20.72650020.820.820.920.9
    50Capacity (w)253003010037270475105212057080
    Input (w)122191229312334123311234212352
    Current (Amps)2222.122.222.222.222.2
    55Capacity (w)2858035540454104985054600
    Input (w)1363113707137301373013720
    Current (Amps)23.823.9242424

    Note:

    4.4 Deg Return Gas, no Sub-Cooling, 35 Deg Ambient
    Supplied with: Internal Motor Protection, Rubber Mounting Kit
    IMPORTANT – WARNING : Read Installation Notes Before Running Any Scroll Compressors
