Danfoss Scroll Compressor 3PH R407C R22 PVE Oil Stub Tube - HRP060T4LP6

Danfoss Scroll Compressor 3PH R407C R22 PVE Oil Stub Tube

Part Number: HRP060T4LP6

Danfoss Scroll Compressor 3PH R407C R22 PVE Oil Stub Tube

Part Number: HRP060T4LP6
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • Danfoss H-Series Scroll Compressors are 100% gas cooled & fitted with an automatic reset line break protector mounted internally on the motor windings.

    The internal protectors respond to over-current, overheating & are designed to interrupt motor current under a variety of fault conditions such as failure to start, running overload & fan failure etc.

    If the internal overload protector trips it must cool down to approximately +60 degrees Celsius to reset. (Depending on the ambient temperature this may take up to several hours)

    Three Phase Sequence & Reverse Rotation Protection

    The compressor will only operate properly with the correct rotation. If a three phase compressor is wired incorrectly it will run but will have excessive noise, no pressure differential between suction & discharge, plus the suction will become warmer rather than cooler.

    The smaller range of Danfoss H-Series scroll compressors (up to HLP075) are able to run in reverse rotation safely for up to 150 hours without damaging the compressor, however phase monitors are still recommended.

    The larger range of Danfoss H-Series scroll compressors (HLP078 onwards) should never be run in reverse. Danfoss recommends phase rotation protection should always be fitted to prevent these compressors from operating in reverse rotation.

    Single Phase Compressors – Reverse Rotation

    Brief power interruptions may cause reverse rotation of single phase scroll compressors. The internal protection will stop the compressor & once cooled down will restart with correct rotation.

    Crankcase heaters are recommended on all stand-alone compressors & split systems. The heater should be energised for a minimum of 12 hours before initial start up (compressor service valves opened) & must remain energised whenever the compressor is off.

    External High Pressure Switches are required for HCP094,109,120 scroll compressors as these models are not equipped with internal pressure relief valves.

    Note: Crankcase heater is not supplied with compressor & should be purchased separately if required.



  • General Specifications
    Nominal HP5 HP
    Displacement14.1 m³/Hr
    Swept Volume80.95 cm³
    Suction Line ConnectionStub Tube 7/8" ODF
    Discharge Line ConnectionStub Tube 1/2" ODF
    Weight38.83 kg
    Oil Charge1.57 L
    Oil TypePVE Oil 320HV
    Electricsround electrical box with spade terminals
    Electrical Specifications
    Voltage380-415/3/50
    Motor Type3PH
    Max Continuous Current15 amps
    Locked Rotor Amps70 amps
    Rated Load Amps9.6 amps
    Crankcase Heater 150watt, 230volt

    1. Crankcase Heaters are not supplied with compressors & should be purchased separately if required

  • ContactorMC18B240V
    Thermal OverloadMT323K18
    Electronic OverloadGMP223P22A
    Crankcase Heater120Z0057
  • danfoss_scroll_dim_2

    Units Dimensions (mm)
    D184
    H455
    H1280
    H2422
  • R22
    Cond Temp (°C)Evaporating Temperature (°C)
    -15-10-5057.210
    45Capacity (w)652582111019312439149161609317590
    Input (w)3421342334513490352635343545
    Current (Amps)6.26.196.186.176.176.176.18
    50Capacity (w)58867591956311769141761530916752
    Input (w)3736376338103862390739173930
    Current (Amps)6.936.96.886.866.866.876.88
    55Capacity (w)6842882911021133851448615888
    Input (w)406541514237431143314357
    Current (Amps)7.767.727.77.77.717.72

    Note:

    Rating Conditions 11.1k Superheat, 8.3K Subcooling
    R407C
    Cond Temp (°C)Evaporating Temperature (°C)
    -15-10-5057.210
    45Capacity (w)61827780967311894144731577817440
    Input (w)3610357635513538354135513563
    Current (Amps)6.0366.036.086.086.045.99
    50Capacity (w)57437244902711121135591479616370
    Input (w)4077401339603923390339043905
    Current (Amps)6.446.386.46.446.456.426.38
    55Capacity (w)6689835710321126131377915263
    Input (w)449544184358431943134305
    Current (Amps)6.96.936.987.0276.98

    Note:

    Rating Conditions 11.1k Superheat, 8.3K Subcooling
