Danfoss Scroll Compressor 3PH R407C R22 PVE Oil Stub Tube - HLP081T4LC6

Danfoss Scroll Compressor 3PH R407C R22 PVE Oil Stub Tube

Part Number: HLP081T4LC6

Danfoss Scroll Compressor 3PH R407C R22 PVE Oil Stub Tube

Part Number: HLP081T4LC6
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • Danfoss H-Series Scroll Compressors are 100% gas cooled & fitted with an automatic reset line break protector mounted internally on the motor windings.

    The internal protectors respond to over-current, overheating & are designed to interrupt motor current under a variety of fault conditions such as failure to start, running overload & fan failure etc.

    If the internal overload protector trips it must cool down to approximately +60 degrees Celsius to reset. (Depending on the ambient temperature this may take up to several hours)

    Three Phase Sequence & Reverse Rotation Protection

    The compressor will only operate properly with the correct rotation. If a three phase compressor is wired incorrectly it will run but will have excessive noise, no pressure differential between suction & discharge, plus the suction will become warmer rather than cooler.

    The smaller range of Danfoss H-Series scroll compressors (up to HLP075) are able to run in reverse rotation safely for up to 150 hours without damaging the compressor, however phase monitors are still recommended.

    The larger range of Danfoss H-Series scroll compressors (HLP078 onwards) should never be run in reverse. Danfoss recommends phase rotation protection should always be fitted to prevent these compressors from operating in reverse rotation.

    Single Phase Compressors – Reverse Rotation

    Brief power interruptions may cause reverse rotation of single phase scroll compressors. The internal protection will stop the compressor & once cooled down will restart with correct rotation.

    Crankcase heaters are recommended on all stand-alone compressors & split systems. The heater should be energised for a minimum of 12 hours before initial start up (compressor service valves opened) & must remain energised whenever the compressor is off.

    External High Pressure Switches are required for HCP094,109,120 scroll compressors as these models are not equipped with internal pressure relief valves.

    Note: Crankcase heater is not supplied with compressor & should be purchased separately if required.



  • General Specifications
    Nominal HP7 HP
    Displacement19.3 m³/Hr
    Swept Volume110.94 cm³
    Suction Line ConnectionStub Tube 7/8" ODF
    Discharge Line ConnectionStub Tube 3/4" ODF
    Weight40.25 kg
    Oil Charge1.57 L
    Oil TypePVE Oil 320HV
    Electricssquare electrical box with screw terminals
    Electrical Specifications
    Voltage380-415/3/50
    Motor Type3PH
    Max Continuous Current17 amps
    Locked Rotor Amps87 amps
    Rated Load Amps11 amps
    Crankcase Heater 170watt, 230volt

    1. Crankcase Heaters are not supplied with compressors & should be purchased separately if required

  • ContactorMC22B240V
    Thermal OverloadMT323K22
    Electronic OverloadGMP223P22A
    Crankcase Heater120Z0059
  • danfoss_scroll_dim_2

    Units Dimensions (mm)
    D184
    H455
    H1280
    H2422
  • R22
    Cond Temp (°C)Evaporating Temperature (°C)
    -15-10-5057.210
    45Capacity (w)9150114481416817278207452241424538
    Input (w)4658468347394800484248424841
    Current (Amps)9.079.059.049.039.039.039.04
    50Capacity (w)8251105421321816245195932119323229
    Input (w)5100516752545339539653985400
    Current (Amps)10.1410.110.0610.0410.0410.0510.07
    55Capacity (w)94831214315118183751991921883
    Input (w)560157505888598860056027
    Current (Amps)11.3511.311.2611.2611.2711.29

    Note:

    Rating Conditions 11.1k Superheat, 8.3K Subcooling
    R407C
    Cond Temp (°C)Evaporating Temperature (°C)
    -15-10-5057.210
    45Capacity (w)8827111071381216982206562251224874
    Input (w)5148513051065070501549784932
    Current (Amps)7.987.947.998.058.088.048
    50Capacity (w)8231103961297215997195112129023555
    Input (w)5675565856385609556155295489
    Current (Amps)8.58.448.488.558.68.588.56
    55Capacity (w)96221206714947183022000422171
    Input (w)623762236201616361366101
    Current (Amps)9.089.149.259.359.369.38

    Note:

    Rating Conditions 11.1k Superheat, 8.3K Subcooling
