ECOLINE series for subcritical CO2 applications with high standstill pressures - ME models
Based on the proven SL-series, a new series has been developed to meet the specific requirements of subcritical CO2 applications with high demands on standstill pressures and condensing temperatures.
The compressors with motor 1 are particularly suited for use in cold-water networks with condensing temperatures of up to 25°C.
The new series combines the high energy efficiency and proven features of the SL compressors with an increased pressure strength of 100 bar at the high and low pressure sides, and an extended application range.
Thus, in response to regional market developments, BITZER is able to provide energy efficient and operationally safe compressors for systems with high demands on permitted pressure levels.
Highlights and technical features:
- 15 compressors with displacements from 1.7 to 64.9 m³/h
- Pressure-proof housing without bottom plate for maximum pressures of up to 100 bar on the high pressure side and the low pressure side
- Two motor versions (for 2 MME..2DME) allowing efficient use in conventional CO2 low temperature systems or in applications with elevated condensing temperatures
- High energy efficiency with new suction gas flow, highly adapted efficient working valves and optimised cylinder heads
