Cubigel Cond Unit HMBP 1Ø CSR-Drier, S/G, Press Cont 3/4HP - CMS26TB6PNB

Cubigel Cond Unit HMBP 1Ø CSR-Drier, S/G, Press Cont 3/4HP

Part Number: CMS26TB6PNB

Cubigel Cond Unit HMBP 1Ø CSR-Drier, S/G, Press Cont 3/4HP

Part Number: CMS26TB6PNB
Cubigel

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • Cubigel Hermetic Flat Base Condensing Units

    Airefrig Australia’s range of Cubigel condensing units are one of the highest quality fractional horsepower units available for the Australian market. The condensing units have many standard fitted features.

    The condensing units are rated to 43°C ambient. Compatible with most Common Refrigerants and Modern Low GWP Refrigerants. High efficiency Compressor model’s reduce energy consumption between 10%-30% compared to standard Compressors (CSR/CSIR).

    The Cubigel condensing unit is the most cost-effective fractional HP condensing unit available ranging in Compressor Displacements from 5.98 cm³ to 34.42 cm³. Suitable for High, Medium or Low Temperature Applications.

    Now available with optional factory fitted Drier, Sight glass and Dual Pressure Control saving time in installation for contractors.

    Standard Fitted Features:
    • Liquid Receiver
    • Galvanised Black Powder Coated Unit Base
    • ebm-papst Condenser Fans

    Options Fitted to Model's with P/N ending in 6PN:

    • Danfoss Drier
    • Danfoss Sight Glass
    • Danfoss Dual LP/HP Pressure control
    • Gomax flexible control hoses

  • Condensing Unit Specifications
    Weight45 Kg
    Liquid Line Connection3/8 "
    Suction Line Connection5/8 "
    Receiver Capacity2.4 L
    Compressor
    Nominal HP1-3/8 HP
    Max Continuous Current11.5 Amps
    Locked Rotor Amps38 Amps
    Voltage240V / 1 / 50Hz
    Motor TypeCSR
    Fan Motors
    Quantity1
    Diameter350 mm
    Voltage240V / 1 / 50Hz
  • cubigel_CUCA0036

    Units Dimensions (mm)
    W485
    D540
    H440
  • R404A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -25-20-15-10-507.210
    3212171551190722872691311737744043
    3811231430175921102482287634813730
    4310561345165319832333270332733507

    Note:

    Performance data based on 35°C return gas (ASHRAE conditions)
    Factory fitted with Dual Pressure Control, Liquid Line Drier & Sight Glass
    R507
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -25-20-15-10-507.210
    3212171551190722872691311737744043
    3811231430175921102482287634813730
    4310561345165319832333270332733507

    Note:

    Performance data based on 35°C return gas (ASHRAE conditions)
    Factory fitted with Dual Pressure Control, Liquid Line Drier & Sight Glass
    R449A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -15-10-507.210
    32167920622480293336233898
    38154819062296272233683620
    43145117912164257131683403

    Note:

    Performance data based on 20°C return gas & inherent sub cooling
    Factory fitted with Dual Pressure Control, Liquid Line Drier & Sight Glass
