Optyma Commercial Flat Base Cond Unit - Low Temp - 3Ø 2-7/8HP

Part Number: OPLCQN136NTA14E

Optyma Commercial Flat Base Cond Unit - Low Temp - 3Ø 2-7/8HP

Part Number: OPLCQN136NTA14E
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

Optyma Commercial Flat Base Cond Unit - Low Temp - 3Ø 2-7/8HP
Optyma Commercial Flat Base Cond Unit - Low Temp - 3Ø 2-7/8HP
Optyma Commercial Flat Base Cond Unit - Low Temp - 3Ø 2-7/8HPOptyma Commercial Flat Base Cond Unit - Low Temp - 3Ø 2-7/8HP

  • Optyma Blue Flat Base Units

    Standard Features

    • Suitable for Multiple Refrigerants (R134A, R513A, R404A/R507,R449A/R448A & R452A)
    • Dedicated Low or Medium Temperature Units
    • ebm-papst 6 Pole AC Fan Motor Assemblies
    • Maneurop Hermetic Reciprocating Compressors
    • Compressor Oil Sight Glass
    • PTC Crankcase Heater
    • Service Shut Off Valves
    • Dual Pressure Control
    • Gomax Pressure Control Lines
    • Liquid Line Drier & Sight Glass
    • Liquid Receiver
    • Compressor Contactor & Overload Relay
    • Pre-wired to Electrical Box

    Externally mounted Service Ports

    • Fast and easy installation
    • Quick connections of suction & liquid lines
    • Shut off valves on receiver
    • Service valves with ports for easy servicing

    Micro Channel Condenser Coil

    • Easy and fast cleaning
    • Less refrigerant charge
    • Longer life time
    • High Efficiency
  • Condensing Unit Specifications
    Weight125 Kg
    Liquid Line Connection1/2 "
    Suction Line Connection7/8 "
    Receiver Capacity7.3 L
    Compressor
    Max Continuous Current14.3 Amps
    Locked Rotor Amps51 Amps
    Voltage400V / 3 / 50Hz
    Motor TypeD.O.L.
    Crankcase HeaterPTC 27watt 230-600V
    Fan Motors
    Total FLA0.97 Amps
    Quantity1
    Diameter500 mm
    Voltage230V / 1 / 50Hz
  • Compressor120F0236
    Comp Suction Service Valve7968016
    Comp Discharge Service Valve7968013
    ebm Fan Motor Assembly118U0392
    PTC Crankcase Heater120Z0459
    Liquid Receiver8168181
    Receiver Shut Off Valve7968014
    Unit Contactor118U5263
    Unit Overload Relay118U5268
    Liquid Line Filter DrierDML084S
    Liquid Line Sight GlassSGP12NSR410A
    HP/LP Control060-539766
    Condenser Coil118U5219
  • danfoss_blue_dim_DFB04
  • danfoss_blue_elec_3
  • R404A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -40-35-30-25-20-15-10
    3222393106414953796803842510245
    381845262035534654593173899032
    4322243062405352056526
    4619902771369547716008

    Note:

    Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
    R507
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -40-35-30-25-20-15-10
    3222393106414953796803842510245
    381845262035534654593173899032
    4322243062405352056526
    4619902771369547716008

    Note:

    Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
    R452A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -35-30-25-20-15-10
    323243429855486997864010472
    38277937034804608675509913
    433234421153556669

    Note:

    Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.

  • Danfoss Optyma Blue Flat Base Condensing Units



    Micro Channel Heat Exchanger technology | A whole new level of system efficiency
