Optyma Commercial Flat Base Cond Unit - Med Temp - 3Ø 2-1/8HP - OPMCRN060MTA14E
Optyma Commercial Flat Base Cond Unit - Med Temp - 3Ø 2-1/8HP
Part Number: OPMCRN060MTA14EOptyma Commercial Flat Base Cond Unit - Med Temp - 3Ø 2-1/8HP
Part Number: OPMCRN060MTA14ESign in to your Aire-Biz account to view pricing and stock levels.
Sign in Not an Airefrig customer? Complete our online account application form here to apply for a credit account.
Optyma Blue Flat Base Units
Standard Features
- Suitable for Multiple Refrigerants (R134A, R513A, R404A/R507,R449A/R448A & R452A)
- Dedicated Low or Medium Temperature Units
- ebm-papst 6 Pole AC Fan Motor Assemblies
- Maneurop Hermetic Reciprocating Compressors
- Compressor Oil Sight Glass
- PTC Crankcase Heater
- Service Shut Off Valves
- Dual Pressure Control
- Gomax Pressure Control Lines
- Liquid Line Drier & Sight Glass
- Liquid Receiver
- Compressor Contactor & Overload Relay
- Pre-wired to Electrical Box
Externally mounted Service Ports
- Fast and easy installation
- Quick connections of suction & liquid lines
- Shut off valves on receiver
- Service valves with ports for easy servicing
Micro Channel Condenser Coil
- Easy and fast cleaning
- Less refrigerant charge
- Longer life time
- High Efficiency
Condensing Unit Specifications | Weight | 90 Kg |
| Liquid Line Connection | 1/2 " |
| Suction Line Connection | 5/8 " |
| Receiver Capacity | 5.2 L |
Compressor | Max Continuous Current | 9 Amps |
| Locked Rotor Amps | 38 Amps |
| Voltage | 400V / 3 / 50Hz |
| Motor Type | D.O.L. |
| Crankcase Heater | PTC 27watt 230-600V |
Fan Motors | Total FLA | 0.97 Amps |
| Quantity | 1 |
| Diameter | 500 mm |
| Voltage | 230V / 1 / 50Hz |
| Compressor | MTZ364VI |
| Comp Suction Service Valve | 7968013 |
| Comp Discharge Service Valve | 7968014 |
| ebm Fan Motor Assembly | 118U0392 |
| PTC Crankcase Heater | 120Z0459 |
| Liquid Receiver | 8168180 |
| Receiver Shut Off Valve | 7968013 |
| Unit Contactor | 118U5262 |
| Unit Overload Relay | 118U5266 |
| Liquid Line Filter Drier | DML164S |
| Liquid Line Sight Glass | SGP12NSR410A |
| HP/LP Control | 060-539766 |
| Condenser Coil | 118U5218 |
R404A | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -20 | -15 | -10 | -5 | 0 | 5 | 10 |
|---|
| 32 | 3238 | 4146 | 5174 | 6317 | 7570 | 8926 | 10376 |
| 38 | 2817 | 3634 | 4555 | 5579 | 6702 | 7919 | 9222 |
| 43 | 2465 | 3205 | 4037 | 4961 | 5975 | | |
| 46 | 2254 | 2947 | 3725 | 4589 | 5537 | | |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
R507 | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -20 | -15 | -10 | -5 | 0 | 5 | 10 |
|---|
| 32 | 3238 | 4146 | 5174 | 6317 | 7570 | 8926 | 10376 |
| 38 | 2817 | 3634 | 4555 | 5579 | 6702 | 7919 | 9222 |
| 43 | 2465 | 3205 | 4037 | 4961 | 5975 | | |
| 46 | 2254 | 2947 | 3725 | 4589 | 5537 | | |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
R449A | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -20 | -15 | -10 | -5 | 0 | 5 | 10 |
|---|
| 32 | 2774 | 3609 | 4575 | 5671 | 6893 | 8235 | 9687 |
| 38 | 2475 | 3234 | 4113 | 5111 | 6226 | 7453 | 8785 |
| 43 | 2227 | 2923 | 3729 | 4645 | 5670 | | |
| 46 | 2080 | 2738 | 3499 | 4365 | 5337 | | |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
R448A | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -20 | -15 | -10 | -5 | 0 | 5 | 10 |
|---|
| 32 | 2774 | 3609 | 4575 | 5671 | 6893 | 8235 | 9687 |
| 38 | 2475 | 3234 | 4113 | 5111 | 6226 | 7453 | 8785 |
| 43 | 2227 | 2923 | 3729 | 4645 | 5670 | | |
| 46 | 2080 | 2738 | 3499 | 4365 | 5337 | | |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
R134A | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -20 | -15 | -10 | -5 | 0 | 5 | 10 |
|---|
| 32 | 1758 | 2330 | 3014 | 3815 | 4736 | 5778 | 6937 |
| 38 | 1564 | 2105 | 2745 | 3491 | 4347 | 5312 | 6385 |
| 43 | 1413 | 1921 | 2521 | 3217 | 4014 | 4913 | 5911 |
| 46 | 1326 | 1814 | 2387 | 3051 | 3811 | 4668 | 5620 |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
R513A | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -20 | -15 | -10 | -5 | 0 | 5 | 10 |
|---|
| 32 | 1671 | 2259 | 2953 | 3763 | 4690 | 5736 | 6900 |
| 38 | 1468 | 2018 | 2663 | 3412 | 4269 | 5235 | 6310 |
| 43 | 1288 | 1803 | 2405 | 3101 | 3897 | 4795 | 5796 |
| 46 | 1176 | 1669 | 2243 | 2907 | 3666 | 4523 | 5479 |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
R425A | Ambient (°C) | Refrigeration Capacity (w) |
|---|
| Evaporating Temperature (°C) |
|---|
| -25 | -20 | -15 | -10 | -5 | 0 | 5 |
|---|
| 32 | 2355 | 3008 | 3785 | 4692 | 5734 | 6911 | 8218 |
| 38 | 2076 | 2666 | 3364 | 4178 | 5113 | 6170 | 7348 |
| 43 | 1835 | 2368 | 2996 | 3730 | 4573 | 5530 | |
| 46 | 1687 | 2184 | 2770 | 3453 | 4242 | 5138 | |
Note:
Nominal ratings should be used as a guide, based on EN13215 10K Superheat & 0 liquid subcooling.
Danfoss Optyma Blue Flat Base Condensing Units
Micro Channel Heat Exchanger technology | A whole new level of system efficiency
