  • Enthalpy TD Semi-Hermetic Condensing Units

    Airefrig Australia’s range of Enthalpy condensing units is one of the highest quality units available for the Australian market. The condensing units have many standard fitted features, previously being options.

    The condensing units are rated to 43 ambient and are fitted with a fan speed controller. This means they can be applied in the hot climate of far North Queensland to the cooler areas of Tasmania.

    The Enthalpy condensing unit is the most complete condensing unit available saving time in installation for contractors.

    Standard Fitted Features:

    • Weatherproof White Powder coated unit casing
    • Semi-Hermetic Bitzer Compressors
    • Compressor oil sight glass
    • Crankcase Heater
    • HP/LP Control
    • Gomax Flexible Control Hoses
    • Liquid Line Drier & Sight Glass
    • Oil separator (Pre-charged with Poe oil)
    • Liquid Receiver• Supercoatcondenser treatment (5000 Hour Salt Spray Test)
    • Top Discharge High Ambient Condenser
    • Space saving unit design (Can be installed into a corner or back to back)
    • ebm-papst condenser Fans – single Phase
    • Saginomiya Condenser Fan Speed Controller
    • 3PH Contactor & Electronic Motor Protection Relay
    • Phase Loss & Phase Imbalance Protection
    • Dust & Weatherproof Electrical Box
    • Pre-Wired Back to Electrical Box
    • 1.22mm (18G) Interconnecting Copper Pipe Work
    • Pre-Drilled ready to fit IPW series isolating switch
    • Discharge Vibration Eliminator
    • Suction Accumulator
  • Condensing Unit Specifications
    Weight505 Kg
    Liquid Line Connection3/4 "
    Suction Line Connection1-3/8 "
    Receiver Capacity R404A34 Kg
    Compressor
    Nominal HP20 HP
    Max Continuous Current33.2 Amps
    Voltage380-400V / 3 / 50Hz
    Motor TypeP.W.S.
    Crankcase Heater230V / 1 / 50Hz 140w
    Fan Motors
    Total FLA8.1 Amps
    Quantity3
    Diameter630 mm
    Voltage230V / 1 / 50Hz
    Sound Data
    High Speed63 dB(A)
    Speed Controlled61 dB(A)
  • Compressor Model4NES20Y
    Compressor ContactorMC22B240V
    Compressor Electronic OverloadGMP223P22A
    Circuit Breaker Control CircuitPLSMD4
    Circuit Breaker Condenser FansPLSMD16
    Oil Separator (Internal Float)EOS1011
    Liquid ReceiverHHR018
    Receiver Outlet ValveR052FB4DS
    Receiver Outlet Gasket020002802PK
    Receiver Inlet ValveR053FB7DS
    Receiver Inlet Gasket020002802PK
    Unit Electrical BoxEUR604015
    Liquid Line DrierC416S
    Liquid Line Sight GlassSA16S
    Suction Accumulator1010854P
    Unit Start Delay TimerICM105
    Compressor CRII Solenoid Valve34760147
    Compressor Oil Monitor34731602
    Oil Return StrainerSH9105
    Liquid Line Drier ShellNFDS487
    Liquid Line Drier CoreRC4864
    Low Pressure ControlSNSC106X
    High Pressure ControlSNSC130X
    CM-RC-01 Control Module34702850
    Compressor Head Cooling Fan34302129
    Low Pressure Transducer (Carel)SPKT0143P0
    High Pressure Transducer (Carel)SPKT0033P0
    Condenser Fan Model (ebm)S6E630AN0101
    Fan Speed ControllerRGEZ1Q45MFQ1
    TD Case ModelMP57
  • Enthalpy_TD-E
  • (B24)TD15
  • R404A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -40-35-30-25-20-15-10-505
    327549102191337617054212772607231437373714385750855
    38655889761184515194190482342228312337113958945904
    4357647974106051368217222212412572730668

    Note:

    Nominal ratings should be used as a guide, based on 20 degree Celsius return vapour and inherent liquid subcooling.
    Compressor fitted with CRII 10-100% capacity regulation (CM-RC-01 module controlled by Carel DN33) & head cooling fan
    1 phase AC fans are speed controlled via Saginomiya RGEZ controller
    Saginomiya fan speed controller is set for continuous running @ low speed, select fan OFF option at low speed in low ambient applications to prevent over condensing.
    Fitted with suction accumulator, oil return strainer, liquid receiver, liquid line drier shell & sight glass
    Fitted with oil separator (internal float)
    Requires additional cooling &/or return vapour limitations - Contact Airefrig Australia for further information.
    R507
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -40-35-30-25-20-15-10-505
    327549102191337617054212772607231437373714385750855
    38655889761184515194190482342228312337113958945904
    4357647974106051368217222212412572730668

    Note:

    Nominal ratings should be used as a guide, based on 20 degree Celsius return vapour and inherent liquid subcooling.
    Compressor fitted with CRII 10-100% capacity regulation (CM-RC-01 module controlled by Carel DN33) & head cooling fan
    1 phase AC fans are speed controlled via Saginomiya RGEZ controller
    Saginomiya fan speed controller is set for continuous running @ low speed, select fan OFF option at low speed in low ambient applications to prevent over condensing.
    Fitted with suction accumulator, oil return strainer, liquid receiver, liquid line drier shell & sight glass
    Fitted with oil separator (internal float)
    Requires additional cooling &/or return vapour limitations - Contact Airefrig Australia for further information.
    R449A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -40-35-30-25-20-15-10-505
    32601884841147015026191952402629549357854276250470
    3874701020913481173292180126916326963915846288
    436654919012229158121998024752301453616842805

    Note:

    Nominal ratings should be used as a guide, based on 20 degree Celsius return vapour and inherent liquid subcooling.
    Compressor fitted with CRII 10-100% capacity regulation (CM-RC-01 module controlled by Carel DN33) & head cooling fan
    1 phase AC fans are speed controlled via Saginomiya RGEZ controller
    Saginomiya fan speed controller is set for continuous running @ low speed, select fan OFF option at low speed in low ambient applications to prevent over condensing.
    Fitted with suction accumulator, oil return strainer, liquid receiver, liquid line drier shell & sight glass
    Fitted with oil separator (internal float)
    Requires additional cooling &/or return vapour limitations - Contact Airefrig Australia for further information.
    R513A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -25-20-15-10-50510
    32949412482159691999124585297703556841997
    38856711314145281824222488272813263838571
    43781510364133511680720761252253021235728

    Note:

    Nominal ratings should be used as a guide, based on 20 degree Celsius return vapour and inherent liquid subcooling.
    Compressor fitted with CRII 10-100% capacity regulation (CM-RC-01 module controlled by Carel DN33) & head cooling fan
    1 phase AC fans are speed controlled via Saginomiya RGEZ controller
    Saginomiya fan speed controller is set for continuous running @ low speed, select fan OFF option at low speed in low ambient applications to prevent over condensing.
    Saginomiya fan speed controller will require to be adjusted to suit R513a refrigerant at time of commissioning.
    Fitted with suction accumulator, oil return strainer, liquid receiver, liquid line drier shell & sight glass
    Fitted with oil separator (internal float)
    Requires additional cooling &/or return vapour limitations - Contact Airefrig Australia for further information.
    R134A
    Ambient (°C)Refrigeration Capacity (w)
    Evaporating Temperature (°C)
    -25-20-15-10-50510
    32856611461148781886023455286943460541219
    38774810422135881728721563264413194338101
    4370879580125401600520013245892975335518

    Note:

    Nominal ratings should be used as a guide, based on 20 degree Celsius return vapour and inherent liquid subcooling.
    Compressor fitted with CRII 10-100% capacity regulation (CM-RC-01 module controlled by Carel DN33) & head cooling fan
    1 phase AC fans are speed controlled via Saginomiya RGEZ controller
    Saginomiya fan speed controller is set for continuous running @ low speed, select fan OFF option at low speed in low ambient applications to prevent over condensing.
    Saginomiya fan speed controller will require to be adjusted to suit R134a refrigerant at time of commissioning.
    Fitted with suction accumulator, oil return strainer, liquid receiver, liquid line drier shell & sight glass
    Fitted with oil separator (internal float)
    Requires additional cooling &/or return vapour limitations - Contact Airefrig Australia for further information.
