Buffalo Med Temp Evaporator 3 x 310mm Fan - GACC068MACS0
Buffalo Med Temp Evaporator 3 x 310mm Fan
Part Number: GACC068MACS0Buffalo Med Temp Evaporator 3 x 310mm Fan
Part Number: GACC068MACS0Sign in to your Aire-Biz account to view pricing and stock levels.
Sign in Not an Airefrig customer? Complete our online account application form here to apply for a credit account.
The GACC air coolers are equipped with a staggered tube system, internally grooved tubes and specially pressed fins. Optimised fin systems and adapted pipe circuiting offer safe operation and high efficiency.
Evaporator Specifications | Weight Unpacked | 42 kg |
| Inlet Connection | 16 mm |
| Outlet Connection | 28 mm |
Air Flow | Air Flow | 4260 m³/h |
| Air Throw - STD Fan | 8 m |
Fan Motors | Voltage | 230V / 1 / 50Hz |
| Quantity | 3 |
| Diameter | 310 mm |
| Total Watts | 270 watts |
| Total Amps | 1.2 amps |
| Units Dimensions (mm) |
|---|
| L | 1672 |
| B | 430 |
| H | 455 |
| E | 1380 |
| F | 332 |
| C | 165 |
| A | 300 |
| ØD | 11 |
| K | G3/4 |
R404A | Capacity (w) @ 6 KTD |
|---|
| SST (?C) |
|---|
| -10 | -8 | -6 | -4 | -2 | 0 | 2 | 4 | 6 |
|---|
| 5742 | 5940 | 6270 | 6600 | 6897 | 7722 | 8118 | 8448 | 8910 |
Note:
Capacities bases on Fin Series 4
R134A | Capacity (w) @ 6 KTD |
|---|
| SST (?C) |
|---|
| -10 | -8 | -6 | -4 | -2 | 0 | 2 | 4 | 6 |
|---|
| 5919.48 | 6123.6 | 6463.8 | 6804 | 7110.18 | 7960.68 | 8368.92 | 8709.12 | 9185.4 |
Note:
Capacities bases on Fin Series 4
R507 | Capacity (w) @ 6 KTD |
|---|
| SST (?C) |
|---|
| -10 | -8 | -6 | -4 | -2 | 0 | 2 | 4 | 6 |
|---|
| 5569.74 | 5761.8 | 6081.9 | 6402 | 6690.09 | 7490.34 | 7874.46 | 8194.56 | 8642.7 |
Note:
Capacities bases on Fin Series 4
