Copeland Scroll Compressor 3PH POE Rotalocks Not Included - ZR190KCETFD523

Copeland Scroll Compressor 3PH POE Rotalocks Not Included

Part Number: ZR190KCETFD523

Copeland Scroll Compressor 3PH POE Rotalocks Not Included

Part Number: ZR190KCETFD523
Copeland

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • ZR190KCE-TFD-523 COPELAND ZR SCROLL COMPRESSORS

    ZR Copeland Scroll compressors for comfort and process/precision cooling applications. Applied in the air conditioning and comfort industry for water chillers, rooftops and close control unit applications, scroll compressors are now the most used compression technology replacing reciprocating and screw compressors due to its undeniable superiority.

    Features and Benefits:

    • Copeland Scroll axial and radial compliance for superior reliability and efficiency

    • Wide scroll line-up for R407C and R134a

    • Low TEWI (Total Equivalent Warming Impact)

    • Low sound and vibration level

    • Low oil circulation rate

    • Copeland qualified tandem and trio configurations for superior seasonal efficiency

  • General Specifications
    Nominal HP15 HP
    Displacement249.1 m³/Hr
    Suction Line Connection1-3/4" 12UNF x 1-3/8 ODF
    Discharge Line Connection1-1/4" 12UNF x 7/8 ODF
    Connection Typerotalock
    Weight67 kg
    Oil Charge3.14 L
    Oil TypePOE
    Oil Sight GlassNo
    Electrical Specifications
    Motor Type3PH
    Max Continuous Current42 amps
    Locked Rotor Amps174 amps
    Rated Load Amps30 amps
    Crankcase Heater 1240V 90W (CH-255) Wrap Around
    Line to Line Resistance0.83 OHMS (+/- 7%)

    1. not supplied

  • Model NumberZR190KCETFD523
    Suction Service ValveR053FC8DS
    Suction Service Gasket020002803PK
    Discharge Service ValveR052FB7DS
    Discharge Service Gasket020002802PK
    ContactorMC40A240A
    Thermal OverloadMT323K32
    Crankcase Heater018004701
  • copeland_ZR_02

    Units Dimensions (mm)
    A243
    B285
    C279
    D232
    E174
    F553
    G585
  • R22
    Cond Temp (°C)Evaporating Temperature (°C)
    -10-507.21012.8
    45Capacity (w)253003150039000500005550060500
    Input (w)109001100011100112001130011300
    Current (Amps)21.92530022.222.422.422.5
    50Capacity (w)230002940036500475005300057500
    Input (w)121001220012300124001250012500
    Current (Amps)23.523.723.8242424.1
    55Capacity (w)2670033500445005000054500
    Input (w)1360013700138001380013800
    Current (Amps)25.525.725.825.925.9

    Note:

    4.4 Deg Return Gas, no Sub-Cooling, 35 Deg Ambient
    Supplied with: Internal Motor Protection, Rubber Mounting Kit
    IMPORTANT – WARNING : Read Installation Notes Before Running Any Scroll Compressors
